Trimble T110 Tablet

Experience maximum, uninterrupted productivity with this rugged, integrated solution.

Powerful

The Trimble T110 tablet has the power you need to get the job done. The T110's 14th Gen Intel Core Ultra 7 processor and intelligent power management system lets you focus on your work, not your battery.

Ensuring uninterrupted productivity in the field, the T110's all-day battery and quick-swap functionality facilitates continuous scanning or data capture.

Efficient

Boost field productivity with the T110 tablet's rapid processing power, dynamic and rugged design, enabling faster project completion.

Experience a new level of efficiency with the T110 tablet's seamless integration into the Trimble software ecosystem—including Trimble Perspective field software.

Work confidently knowing your data is protected by the T110's advanced security protocols, ensuring safe, secure and readily available information.

Productive

The Intel Core Ultra 7 processor reduces your time in the field, with 32 GB RAM for powerful multitasking and data processing.

The T110 tablet's fast processing minimizes field time and accelerates tasks. Wi‑Fi®, Bluetooth®, 4G LTE and Trimble Empower™ module support allow for single-device connections to any Trimble sensor you need.

Instantly share critical data with all stakeholders via the integrated 4G LTE cellular module.

Standard Features

System
Processor 14th Gen Intel Core Ultra 7 Processor
Memory 32 GB RAM
Storage 1 TB
Display 10.1 in (256 mm) LCD Screen
Camera 8 MP rear camera
Operating System
Microsoft® Windows® 11 IoT Enterprise
Communication
Bluetooth v5.4
Wi-Fi 802.11be
4G LTE worldwide coverage, certified on Verizon and AT&T
Trimble Empower module support - 1x module bay support expansion radio for Trimble robotic total stations
USB 3.0 Type A, USB-C
Standard accessories (included in packout)
Active stylus
Screen protector
Hot-swappable battery
Hand strap
Optional accessories
USB Type C 65 w power adapter with USB Type C cable
Shoulder strap
Single battery charger kit
Compatible software
Trimble Perspective, Trimble FieldLink, Trimble Access™, Trimble Forensics Capture, Trimble Siteworks

Technical Specifications

Temperature
Operating -10 °C to +55 °C (14 °F to 131 °F)
Storage -55 °C to +70 °C (-67 °F to +158 °F)
Humidity 0%–90% non-condensing MIL-STD-810H, Method 507.6, Procedure II (aggravated cycle)
Water and dust proof IP65 (with port access doors closed)
Shock, drop MIL-STD-810H, Method 516.8, Procedure-I, IV
Input/Output
User interface Power button, programmable function keys, battery status system LED, display brightness interface
Display LED backlight, scratch-resistant
Size 256 mm (10.1 in) multi-touch
Resolution 1920 x 1200 px
Brightness 800 Nits
Audio Built-in microphone and speaker
I/O USB-C with PD charging, USB 3.0 Type A
Digital camera 8 MP (rear-facing)
Physical
Size (HxWxD) 7.8 x 11 x 0.79 in (198 x 279 x 20 mm)
Weight 1.4 kg (3.1 lbs)
AC/DC Adaptor
Input 100–240 V AC
Output 20 V, 3.25 A, 65 W, Type-C
GNSS
GPS, QZSS, GLONASS, Galileo, BeiDou
Trimble T110 tablet product overview video
